18-11
Section 18 Playing Back Data Recorded During Navigation
１
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
21
22
23
24
25
APP A
APP B
3 By clicking on the Calendar icon, specify the duration of the logbook data to be output.
The selected dates appear in the output data interval selection boxes.
4 Specify the drive of the output destination from the output destination drive selection
box and the output destination folder from the folder tree.
The [Copy>>] button takes effect.
5 Click on the [Copy>>] button.
The following folder is created in the output destination path, and the navigation record data
having the specified interval is copied to this folder.
Folder name: Playback_120108_120109
Output data end time
[yymmdd]
Output data start time
[yymmdd]
To Next Page
