Section 19 Maintenance & Inspection 19-10
Hardware key information can be confirmed.
1 Click on the [Menu] button on the left Tool Bar.
The menu is displayed.
2 Click on the [Maintenance] - [System Information] button on the menu.
The [System Information] dialog box appears.
3 Click on the [H/W Key] tab.
The hardware key information is displayed.
[1] [X]
Click on this button to close the [System Information] dialog box.
[2] [ARCS Information]
The ARCS PIN number and User Permit are displayed.
[3] [S-63 Information]
The S-63 User Permit is displayed.
[4] [Save to USB Device] (Saving to USB flash memory) button
Click on this button to save the displayed information in a USB flash memory in the text format.
[1]
[4]
[2]
[3]
