JRC JMR-5400 Series User Manual

6-11 Section 6 Settings
5
6
6.3 Alert Settings
6.3.1 Configuring the alerts for the destination
route
When using destination routes, configure the conditions for issuing alerts.
Alerts regarding arrival at the destination and alerts regarding leaving from the route are available.
Procedure
Use the following operation to display the [Route] dialogue in the Edit pane of the [Alert] dialogue.
[Menu] button → Alert → Route
The following table lists the setting items of the [Route] dialogue.
Setting item
Description
Setting value
[WPT Alert] check
box
Specify whether to issue destination arrival/leaving
alerts.
Check it to enable the alert.
Enable: Check.
Disable: Uncheck.
[Alert Type] (WPT
alarm) combo box
Select an alert type if the WPT alarm is ON.
Arrival: An alert is issued when the ship arrives in
the circle with the configured radius.
Break Off: An alert is issued when the ship leaves
the circle with the configured radius.
Arrival/Break Off
[Arrival Radius]
field
When the WPT alarm is ON, set the radius of the
arrival circle of the destination.
0.01 to 99.99 NM
[Route Alert]
check box
Specify whether to issue route entry/leaving alerts.
Check it to enable the alert.
Enable: Check.
Disable: Uncheck.
[Alert Type]
(Route Alert)
combo box
Select an alert type if the route alarm is ON.
XTE: An alert is issued when the ship travels off
the route (specified width).
Approach: An alert is issued when the ship enters the
route (specified width).
XTE/Approach
[XTL] field
When the route alarm is ON, set the route width.
The starboard and port side cross track limits should
be added to this value.
0.01 to 99.99 NM
