4-3 Section 4 Route Planning
4
4.2 Route Display Settings
Configure the route display setting before creating a route.
4.2.1 Configuring [View] - [WPT/Route] from the
menu
Configure the route display settings on the [WPT/Route] dialogue of the [View] menu.
Procedure
Use the following operation to display the [WPT/Route] dialogue on the Edit pane of the [View]
dialogue.
[Menu] → View → WPT/Route
The following table lists and describes the route display settings on the [WPT/Route] dialogue.
Memo
For the route monitoring settings on the [WPT/Route] dialogue, see 5.2.1 Configuring [View] -
[WPT/Route] from the menu.
Setting item
Setting
Setting value
WPT Number,
Comment
Turns on/off the proposed destination number and
comment display.
Check it to enable the setting.
Enabled: Checked
Disabled: Unchecked
[Text Size] combo
box (Destination
Number, Comment)
Switch the text size between Standard and Small
for the destination number and comment.
Standard/Small
Route Numb
Turns on/off the route number display.
Check it to enable the setting.
Enabled: Checked
Disabled: Unchecked
[Text Size] combo
box (Route Number)
Switch the route number text size between
Standard and Small.
Standard/Small
[WPT Label]
Set whether to add "WPT" next to the proposed
destination symbol on the NMEA route.
Check it to enable the setting.
Enabled: Checked
Disabled: Unchecked
[WPT Mark Size]
combo box
Switch the proposed destination symbol size
between Standard and Small.
Standard/Small
