Section 2 Basic Operations and Mode Screen 2-30
2.5.2 Loading/saving the destination route file
On the [File Load/Save] tab, destination route files can be loaded and saved.
The following table lists the items displayed on the [File Load/Save] tab.
File Type
Select a file type. Available types are Own Track, Target Track, and
Loads the file selected on the list.
[Save Current Route and
Destinations]
It is displayed when [Plotter Route] is selected as the file type.
The currently stored destination route and proposed destination are
[Delete Current Route and
Destinations]
It is displayed when [Plotter Route] is selected as the file type.
The currently stored destination route and proposed destination are
2.5.2.1 Loading the destination route file
1 Click on the [File Load/Save] tab.
2 Select [Plotter Route] from the [File Type] combo box.
3 Click on the [Load] button.
A confirmation dialogue is displayed.
4 Click on the [OK] button.
The selected file is loaded.
