Appendix A Alert List A-8
The AIS alerts received from external sensors are as shown below.
For the AIS alerts received from external sensors, alert messages are suffixed by (External).
Example: Antenna VSWR exceeds limit (External)
Message Subject Explanation Alert ID
Antenna VSWR exceeds limit AIS Antenna output error 002
Data Flash memory err AIS Transponder data storage circuit error 063
external EPFS lost AIS Abnormality in external EPFS connection 025
general failure AIS General error 006
Heading lost/invalid AIS Ship's heading data has not been input or is
invalid.
032
MKD connection lost AIS Abnormality in the connection between the
transponder and the controller
008
mkd connection lost AIS No response from the transponder (detected in
the display)
064
no sensor position in use AIS Internal GPS data has not been input or is
invalid.
026
no valid COG information AIS COG data has not been input or is invalid. 030
no valid ROT information AIS ROT data has not been input or is invalid. 035
no valid SOG information AIS SOG data has not been input or is invalid. 029
Not Transmitting Tx
malfunction
AIS Malfunction at or during transmission 001
Pa current error AIS Error in the current during transmission 054
Pa temp error AIS Abnormal temperature rise during
transmission
055
Power supply error AIS Error in power supply voltage 053
Program Flash memory err AIS Control circuit error of the transponder 062
Rx channel 1 malfunction AIS Malfunction of reception channel 1 003
Rx channel 2 malfunction AIS Malfunction of reception channel 2 004
Rx channel 70 malfunction AIS Malfunction of reception channel 70 005
SSD mismatch AIS Mismatch in static information (between the
display and the transponder)
065
Tx pll unlock AIS Error in the synthesizer circuit for transmission 060
Tx power down AIS Transmit by reducing output power due to error 051
Tx power supply error AIS Error in power supply voltage during
transmission
052
Tx power too high AIS Power is higher than the specified
transmission power.
059
Tx power too low AIS Power is lower than the specified transmission
power.
056
Tx stop interrupt AIS Transmission is forcibly stopped by the
transmission monitoring circuit.
058
Vr error AIS Transmission system output error 057
