14
󰆵󰅪󰆵
1) 用木螺丝
2
(4 个)把膝动提升装置
1
固定
到机台上。
(木螺丝的位置,请参照机台参考图。
2)
A
所示的那样,请用平头螺丝
4
和螺母
3
进行固定。
( 紧固扭矩为 4.5 5.5N·m,固定背面螺母
3
时,请使用 8mm 扳手。)
3)
拧松
C
的固定螺丝,调整曲柄
D
的角度,
B
部的卷绕装置的前端和助卷动作杆
A
8
之间的间隙为 0mm。
󰆧󰀑
󰅠󰃗󰂟󰅠󰃄󰇼
5
6
7
D
D
󰅄󰇸󰁟
卷套装置开闭机构的最大开闭量为 13mm。
请调整
8
的橡胶部件螺丝的突出量,设定为最大开闭量在 13mm 以内范围的适当的开闭量。

8

4)
5
安装到轴
6
上,然后固定到适当的位置。
A 方向推
7
,确认卷绕装置的开闭动作是
否顺畅。
(如果有异常时,请调整
D
的左右方向。
1
2
3
4
A
B
C
8
D
