. INSTALLATION (DLN-6390)
This item is applied only to the case where DLN-6390 is used.
Max. sewing speed of this sewing machine is 5,000 sti/min (normal speed : 4,500 sti/min). However, when stitch length
is 3.6 mm or more, max. sewing speed is 4,500 sti/min. Select the optimum motor pulley referring to the table below.
＊
Use the HM type V belt.
1) Use a clutch motor with an output of 400 W (1/2 HP) as the standard.
2) Relation among the motor pulley, belt length and sewing speed of the sewing machine is as shown in the table below.
Outside diameter of
motor pulley (mm)
125
120
115
110
105
100
95
90
85
80
75
70
Part No. of motor pulley
MTSP0120000A
MTSP0115000A
MTSP0110000A
MTSP0105000A
MTSP0100000A
MTSP0095000A
MTSP0090000A
MTSP0085000A
MTSP0080000A
MTSP0075000A
MTSP0070000A
MTSP0065000A
Sewing speed (sti/min)
50 Hz
5,060
4,850
4,630
4,440
4,250
4,000
3,820
3,610
3,390
3,160
2,950
2,740
60 Hz
5,040
4,780
4,540
4,320
4,000
3,790
3,520
3,260
Belt length
mm (inch)
1321 (52)
1295 (51)
1270 (50)
1245 (49)
Part No. of belt
MTJVH005200
MTJVH005100
MTJVH005000
MTJVH004900
1. Selecting the motor pulley and the belt
WARNING :
To protect against possible personal injury due to abrupt start of the machine, be sure to start the
following work after turning the power off and ascertaining that the motor is at rest.
• Effective diameter of the motor pulley is obtained by subtracting 5 mm from the outside diameter.
• Direction of rotation of the motor is counterclockwise as observed from the pulley. Take care not to allow the pulley to
turn in the reverse direction.
•
When the aforementioned motor pulley and the belt are used, the chain connecting the pedal and the presser foot lifting
mechanism may interfere with the motor due to the kind of the motor. In this case, change the length of the aforemen-
tioned belt and adjust the position of the motor to the position where the motor does not interfere with the chain.
