JUKI DLN-6390 - Installing The Thread Stand

4
2. Installing the thread stand
1) Assemble the thread stand unit, and insert it in the hole
in the machine table.
2) Tighten locknut
1
to x the thread stand.
3) For ceiling wiring, pass the power cord through spool
rest rod
2
.
Assemble spool rest rod joint so that it
faces in the direction as shown in the gure.
1
2
100 mm
Spool rest
rod joint
Spool rest
rod joint
Approx. 45˚
