Juniper EX3400 Features Guide

Table 25: show route extensive Output Fields (continued)
Field DescriptionField Name
Indicates the status of a BGP route:
• Accepted—The specified BGP route is imported by the default BGP policy.
• Import—The route is imported into a Layer 3 VPN routing instance.
• Import-Protect—A remote instance egress that is protected.
• Multipath—A BGP multipath active route.
• MultipathContrib—The route is not active but contributes to the BGP multipath.
• Protect—An egress route that is protected.
• Stale—A route that is marked stale due to graceful restart.
route status
When multipoint LDP with multicast-only fast reroute (MoFRR) is configured, the primary upstream
path. MoFRR transmits a multicast join message from a receiver toward a source on a primary path,
while also transmitting a secondary multicast join message from the receiver toward the source on
a backup path.
Primary Upstream
When multipoint LDP with MoFRR is configured, the reverse-path forwarding (RPF) next-hop
information. Data packets are received from both the primary path and the secondary paths. The
redundant packets are discarded at topology merge points due to the RPF checks.
RPF Nexthops
Multiple MPLS labels are used to control MoFRR stream selection. Each label represents a separate
route, but each references the same interface list check. Only the primary label is forwarded while all
others are dropped. Multiple interfaces can receive packets using the same label.
Label
Value used to distinguish MoFRR primary and backup routes. A lower weight value is preferred. Among
routes with the same weight value, load balancing is possible.
weight
MPLS label assigned to the Layer 2 circuit virtual connection.VC Label
Maximum transmission unit (MTU) of the Layer 2 circuit.MTU
VLAN identifier of the Layer 2 circuit.VLAN ID
(For route reflected output only) Cluster ID sent by the route reflector.Cluster list
(For route reflected output only) Address of router that originally sent the route to the route reflector.Originator ID
Forwarding Equivalent Class (FEC) bound to this route. Applicable only to routes installed by LDP.Prefixes bound to route
Community path attribute for the route. See the Output Field table in the show route detail command
for all possible values for this field.
Communities
Layer 2 encapsulation (for example, VPLS).Layer2-info: encaps
Control flags: none or Site Down.control flags
Maximum transmission unit (MTU) information.mtu
First label in a block of labels and label block size. A remote PE routing device uses this first label
when sending traffic toward the advertising PE routing device.
Label-Base, range
Copyright © 2017, Juniper Networks, Inc.420
DHCP and Other System Services Feature Guide for EX2300, EX3400, and EX4300 Switches

Juniper EX3400 Specifications

General

Switch type	Managed
Switch layer	L2/L3
Quality of Service (QoS) support	Yes
Safety	UL-UL60950-1, C-UL CAN/CSA 22.2 No.60950-1, TUV/GS to EN 60950-1, CB-IEC60950-1, EN 60825-1
Form factor	1U
Product color	Black
Electromagnetic compatibility	FCC 47CFR 15 A, EN 55022 A, ICES-003 A, VCCI A, AS/NZS CISPR 22 A, CISPR 22 A, EN 55024, EN 300386, CE
SFP+ module slots quantity	4
QSFP+ module slots quantity	2
Installed SFP+ modules quantity	0
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity	48
Memory type	DRAM
Noise level	35 dB
Flash memory	2000 MB
Processor frequency	1000 MHz
Virtual stacking (units)	10
Throughput	250 Mpps
Jumbo frames	9216
MAC address table	32000 entries
Number of VLANs	4093
Networking standards	IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3u, IEEE 802.3z
Virtual LAN features	Port-based VLAN
Copper ethernet cabling technology	10BASE-T, 100BASE-T, 1000BASE-T
Power consumption (max)	120 W
Number of power supply units	1
Operating altitude	0 - 3048 m
Non-operating altitude	3048 - 4877 m
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 45 °C
Storage relative humidity (H-H)	0 - 95 %
Operating relative humidity (H-H)	10 - 85 %
DHCP features	DHCP server, DHCP client
Authentication	MAC-based authentication, Port-based authentication
Security algorithms	802.1x RADIUS, HTTPS, SNMP, SSH-2
Fiber ethernet cabling technology	1000BASE-X

Weight and Dimensions

Depth	350 mm
Width	437 mm
Height	44 mm
Weight	5740 g
