Juniper SRX4600

The serial number ID label is on the top of the fan module. See Figure 49 on page 144.
Figure 49: SRX4600 Services Gateway Fan Module Serial Number Location
g009535
Serial number ID label
Locating the Serial Number ID Labels on SRX4600 Services Gateway SSDs
The two SSDs installed in the SRX4600 Services Gateway are field-replaceable unit (FRUs). For each FRU,
you must remove the FRU from the services gateway chassis to see the FRU serial number ID label.
The serial number ID label is on the top of the SSD. See Figure 50 on page 144.
Figure 50: SRX4600 Services Gateway SSD Serial Number Location
4. SSD
g009856
1
SN: XXXXXXXXXXX
1—Serial number
144
