The SRX4600 Services Gateway chassis is a rigid sheet metal structure that houses all the services gateway
components.
Chassis Physical Specifications
Table 3 on page 24 summarizes the physical specifications for the services gateway chassis.
Table 3: SRX4600 Services Gateway Chassis Physical Specifications
ValueDescription
Height: 1.72 in. (4.36 cm)Chassis
Depth
•
26.50 in. (67.31 cm) (front to rear, excluding handles of the Fan/PSU)
•
27.29 in. (69.31 cm) (front to rear, including handles of the Fan/PSU of an SRX4600
Services Gateway AC Model)
•
29.2 in. (74.168 cm) (front to rear, including handles of the Fan/PSU of an SRX4600
Services Gateway DC Model)
Width
•
17.36 in. (44.09 cm) (without the side-mounting brackets)
•
19.00 in. (48.03 cm) (with the side-mounting brackets)
Weight: 2.3 lb (1.04 kg)Fan module
Weight: 3.4 lb (1.54 kg)AC power supply
Weight: 4.4 lb (1.99 kg)DC power supply
An AC device weighs approximately 38 lb (17.23 kg)Services gateway weight
A DC device weighs approximately 40 lb (18.14 kg)
1 U, standard 19-inch rack-mountable.Form factor
Chassis Front Panel
Figure 4 on page 25 shows the front panel of the SRX4600 Services Gateway.
