SRX4600 Alarm and Management Cable Specifications
and Pinouts
IN THIS SECTION
Management Cable Specifications | 53
RJ-45 Management Port Connector Pinout Information | 54
Console Port Connector Pinout Information | 54
RJ-45 to DB-9 Serial Port Adapter Pinout Information | 55
RJ-45 Port, QSFP+ Port, QSFP28 Port, SFP+ Port, and SFP Port Connector Pinout Information | 56
Management Cable Specifications
Table 23 on page 53 lists the specifications for the cables that connect the console and management ports
to management devices.
Table 23: Specifications of Cables to Connect to Management Devices
Additional InformationReceptacleCable SpecificationsPorts
“Connecting a Device to a
Management Console Using
an RJ-45 Connector” on
page 71
RJ-45CAT5e UTP (unshielded
twisted pair) cable
RJ-45 Console port
“Connecting a Device to a
Network for Out-of-Band
Management” on page 72
RJ-45Ethernet cable with an
RJ-45 connector
Management Ethernet port
Mini-USBMini-USB cable with
standard-A and Mini-USB
Type-B (5-pin) connector
Mini-USB Type-B Console
port
53
