Keithley 2701

Model 2701 User’s Manual SCPI Reference Tables 15-11
[SENSe[1]]
:CURRent[:DC] Path to configure DC current. Sec 3 ✓
:APERture <n> [, <clist>] Set integration rate in seconds
(3.333333e-5 to 1).
(Note 2) Sec 4
:APERture? [<clist>] Query aperture integration rate.
:NPLCycles <n> [, <clist>] Set integration rate in line cycles (60Hz;
0.002 to 60, 50Hz; 0.002 to 50).
5.0 Sec 4 ✓
:NPLCycles? [<clist>] Query line cycle integration rate. ✓
:RANGe Path to set measurement range: Sec 4 ✓
[:UPPer] <n> [, <clist>] Select range (0 to 3.1). 3 ✓
[:UPPer]? [<clist>] Query range. ✓
:AUTO <b> [, <clist>] Enable or disable auto range. ON ✓
:AUTO? [<clist>] Query state of auto range. ✓
:DIGits <n> [, <clist>] Specify measurement resolution (4 to 7). 7 Sec 4
:DIGits? [<clist>] Query resolution.
:REFerence <n> [, <clist>] Specify reference (-3.1 to 3.1). 0 Sec 5 ✓
:STATe <b> [, <clist>] Enable or disable reference. OFF ✓
:STATe? [<clist>] Query state of reference. ✓
:ACQuire [, <clist>] Use input signal as reference.
:REFerence? [<clist>] Query reference value. ✓
:AVERage Path to configure and control filter: Sec 4
:TCONtrol <name> Select filter type: (MOVing or REPeat). (Note 3)
:TCONtrol? Query filter type.
:WINDow <NRf> Set filter window in % of range
(0 to 10).
0.1
:WINDow? Query filter window.
:COUNt <n> [, <clist>] Specify filter count (1 to 100). 10
:COUNt? [<clist>] Query filter count.
[:STATe] <b> [, <clist>] Enable or disable filter. (Note 4)
[:STATe]? [<clist>] Query state of digital filter.
Table 15-5 (continued)
SENSe command summary
Command Description
Default
parameter Ref SCPI
