Keithley 2701 User Manual

Model 2701 User’s Manual SCPI Reference Tables 15-17
[SENSe[1]]
:FREQuency Path to configure frequency. Sec 3
:APERture <n> [, <clist>] Sets gate time for frequency
measurements in seconds (0.01 to 1.0).
1.0 Sec 4
:APERture? [<clist>] Query frequency gate time.
:DIGits <n> [, <clist>] Specify measurement resolution (4 to 7). 7 Sec 4
:DIGits? [<clist>] Query resolution.
:REFerence <n> [, <clist>] Specify reference (0 to 1.5e7). 0 Sec 5
:STATe <b> [, <clist>] Enable or disable reference. OFF
:STATe? [<clist>] Query state of reference.
:ACQuire [, <clist>] Use input signal as reference.
:REFerence? [<clist>] Query reference value.
:THReshold Path to select the threshold voltage range: Sec 3 ✓
:VOLTage ✓
:RANGe <n> [, <clist>] Select threshold range (0 to 1010). 10
:RANGe? [<clist>] Query threshold range.
:PERiod Path to configure period: Sec 3
:APERture <n> [, <clist>] Sets gate time for period measurements in
seconds (0.01 to 1.0).
1.0 Sec 4
:APERture? [<clist>] Query period gate time.
:DIGits <n> [, <clist>] Specify measurement resolution (4 to 7). 7 Sec 4
:DIGits? [<clist>] Query resolution.
:REFerence <n> [, <clist>] Specify reference (0 to 1). 0 Sec 5
:STATe <b> [, <clist>] Enable or disable reference. OFF
:STATe? [<clist>] Query state of reference.
:ACQuire [, <clist>] Use input signal as reference.
:REFerence? [<clist>] Query reference value.
:THReshold Path to select the threshold voltage range: Sec 3
:VOLTage
:RANGe <n> [, <clist>] Select threshold range (0 to 1010). 10
:RANGe? [<clist>] Query threshold range.
Table 15-5 (continued)
SENSe command summary
Command Description
Default
parameter Ref SCPI

Keithley 2701 Specifications

General

Max Voltage	300 V
Max Current	3 A
Frequency Range	3 Hz to 500 kHz
Frequency Accuracy	0.01%
Weight	3.6 kg
Measurement Functions	Frequency, Temperature
Interface	IEEE-488 (GPIB), RS-232
DC Voltage Range	300 V
DC Current Range	3 A
AC Voltage Range	300V
AC Current Range	1 μA to 3 A
Resistance Accuracy	0.01%
Channels	10
Dimensions	213mm x 88mm x 370mm
