15-24 SCPI Reference Tables Model 2701 User’s Manual
SYSTem
:COMMunicate
:ETHernet
:DHCP? Query state of DHCP.
:MAC? Returns MAC address of 2701; 6
hexadecimal values separated by colons
(00:60:1A:00:04:0B).
:SERial RS-232:
:BAUD <n> Set baud rate; 300, 600, 1200, 2400, 4800,
9600, 19200, 38400, 57600, or 115200.
✓
:BAUD? Query baud rate. ✓
:PACE <name> Control Xon/Xoff flow control; XON (on) or
NONE (off).
✓
:PACE? Query state of flow control. ✓
:TERMinator <name> Select output terminator; CR, LF, CRLF, or
LFCR.
✓
:TERMinator? Query output terminator ✓
:CONTrol Control RTS/CTS hardware handshaking: ✓
:RTS <name> Enable (IBFull or RFR) or disable (OFF)
hardware handshaking.
✓
:RTS? Query state of hardware handshaking. ✓
:SEND <data> Send data (from serial port) to another
instrument.
4
:ENTer? Read data from serial port.
4
Note:
1. If there is no card in the specified slot, error -241 Hardware Missing will occur.
2. If a pseudocard is installed in the slot, the message "????????" will be returned when querying the serial number or firmware
revision.
3. Power-up and *CLS clears the error queue. *RST, SYSTem:PRESet and STATus:PRESet has no effect on the error queue.
4. Valid only when Ethernet is the selected interface.
Table 15-7 (continued)
SYSTem command summary
Command Description
Default
parameter Ref SCPI
