1-24 Getting Started Model 2701 User’s Manual
Table 1-4
Default settings
Setting Factory *RST Set Diff
Auto channel configuration No (off) No effect ✓
Autozero On On
Buffer No effect No effect
Auto clear Yes (on) No effect ✓
Channel Average Off Off
Closed channels None None
Closure count interval No effect No effect
Continuity
Beeper On On
Digits 4½ digits 4½ digits
Range 1kΩ 1kΩ
Rate Fast (0.01 PLC) Fast (0.01 PLC)
Threshold level 10Ω 10Ω
Current (AC and DC)
Bandwidth (AC) 30 30
Digits (AC) 5½ digits 5½ digits
Digits (DC) 6½ digits 6½ digits
Filter On Off ✓
Window 0.1% 0.1%
Count 10 10
Type Moving Repeat ✓
Range Auto Auto
Rate (DC) Slow (5 PLC) Slow (5 PLC)
Rel Off Off
Ethernet settings:
IP address No effect No effect
Subnet No effect No effect
Gateway No effect No effect
MAC No effect No effect
Frequency and Period
Digits 6½ digits 6½ digits
Range 10V 10V
Rate (aperture) 1 second 1 second
Rel Off Off
Function DCV
Keyclick On On

Keithley 2701 Specifications

General

Max Voltage	300 V
Max Current	3 A
Frequency Range	3 Hz to 500 kHz
Frequency Accuracy	0.01%
Weight	3.6 kg
Measurement Functions	Frequency, Temperature
Interface	IEEE-488 (GPIB), RS-232
DC Voltage Range	300 V
DC Current Range	3 A
AC Voltage Range	300V
AC Current Range	1 μA to 3 A
Resistance Accuracy	0.01%
Channels	10
Dimensions	213mm x 88mm x 370mm
