Keysight InfiniiVision 1200 X-Series and EDUX1052A/G Oscilloscopes

User's Guide

12 Trigger Mode/Coupling

To select the Auto or Normal trigger mode / 122

To select the trigger coupling / 124

To enable or disable trigger noise rejection / 125

To enable or disable trigger HF Reject / 125

To set the trigger holdoff / 126

External Trigger Input / 127

To access the trigger mode and coupling options:

• In the Trigger section of the front panel, press the [Trigger] key.

Default Chapter3
