Snapshot All
The Snapshot All measurement type displays a popup containing a snapshot of all
the single waveform measurements.
You can also configure the [Quick Action] key to display the Snapshot All popup.
See "Configuring the [Quick Action] Key" on page 246.
"DC RMS" on page 164
"AC RMS" on page 165
"Top" on page 161
"+ Width" on page 169
"– Width" on page 169
"X at Max Y" on page 173 Yes The resultant units are in Hertz.
"X at Min Y" on page 173 Yes The resultant units are in Hertz.
*
Use the cursors to make other measurements on FFT.
Measurement Valid for Math FFT
*
Notes
