Keysight InfiniiVision 1200 X-Series and EDUX1052A/G Oscilloscopes

User's Guide

25 CAN Triggering and Serial

Decode

Setup for CAN Signals / 275

CAN Triggering / 277

CAN Serial Decode / 279

CAN triggering and serial decode is available on DSOX1200-Series oscilloscopes.

Setup for CAN Signals

Setup consists of connecting the oscilloscope to a CAN signal, using the CAN

Signals menu to specify the signal source, threshold voltage level, baud rate, and

sample point.

To set up the oscilloscope to capture CAN signals, use the Signals softkey which

appears in the Analyze menu:

1 Press [Display] > Labels > Display to turn on labels.

2 Press the [Analyze] key.

3 Press Features; then, select Serial Bus.

4 Press Features again (or push the Entry knob) to enable the serial bus display.

5 Press the Mode softkey; then, select CAN.

Default Chapter3
