SECTION 4 MODBUS PROTOCOL
Request KLEA Response
Slave ID 0x01 Slave ID 0x01
Function code 0x14 Function code 0x14
Byte Counts 0x07 Byte count 0x16
Sub-req. 1 reference type 0x06 Sub-req. 1 byte count 0x15
Sub-req. 1 file number HI 0x00 Sub-req. 1 reference type 0x06
Sub-req. 1 file number LO 0x11 Timestamp XXX
Sub-req. 1 starting reg. addr. HI 0x00 Timestamp XXX
Sub-req. 1 starting reg. addr. LO 0x00 Timestamp XXX
Sub-req. 1 register count HI 0x00 Timestamp XXX
Sub-req. 1 register count LO 0x0A ----
CRC HI 0xB3 ----
CRC LO 0xD4 ----
The parameters and CRC values in
above tables, are as they should be. On
the other hand, Klea response is given
to describe the message structure. As
a result, values for variables are not
defined.
CRC HI XXX
CRC LO XXX
4.5.3.2 Daily archive data
Recording of daily data changes with start of day (Refer to 3.2.1.1.3.4) setting.
The smallest and largest instantaneous values measured during one day period, are
saved as minimum and maximum values. Likewise, average values of measurements,
which were taken in one day period, are saved as average values.
14h function operates with file numbers. File numbers 5001 – 5240 are used for
DAILY data.
Klea has a memory that is reserved for daily files. It can keep totally 240 daily files.
When Klea’s daily memory is filled completely, oldest record is deleted and new
record is saved in the deleted record’s memory.
