SECTION 3 MENUS
3.2.1.1.4.3 Input 3 Menu (optional)
Input 3 is applicable to optional digital IO Klea models. Input 3 applications and settings are
the same as Input1. Digital input3 operates with DI3 and GND pins.
3.2.1.1.4.4 Input 4 Menu (optional)
Input 4 is applicable to optional digital IO Klea models. Input 4 applications and settings are
the same as Input1. Digital input4 operates with DI4 and GND pins.
3.2.1.1.4.5 Input 5 Menu (optional)
Input 5 is applicable to optional digital IO Klea models. Input 5 applications and settings are
the same as Input1. Digital input5 operates with DI5 and GND pins.
3.2.1.1.4.6 Input 6 Menu (optional)
Input 6 is applicable to optional digital IO Klea models. Input 6 applications and settings are
the same as Input1. Digital input6 operates with DI6 and GND pins.
3.2.1.1.4.7 Input 7 Menu (optional)
Input 7 is applicable to optional digital IO Klea models. Input 7 applications and settings are
the same as Input1. Digital input7 operates with DI7 and GND pins.
3.2.1.1.5 Digital Output Menu
It comprises of Output1 and Output menus.
V1
V2
V3
V
V
V
A
A
A
I1
I2
I3
17:22
0.0
0.0
220.0
5.0
5.0
5.0
V
1 2 3
I
1 2
1 2 E
Setup
Date / Time
System info
Password
Restart
Default settings
Settings
Measure
Meters
Alarms Analysis
Network
Device
Energy
Digital input
Communication
Alarm
Clear
Digital output
Output1
Output2
Fig. 3-34 Digital Output Menu
