Klemsan Klea 320P-D - Measure Menu: Instantaneous and Demand

65
4
Quadrant
Energy Analyzer
4
Quadrant
Energy Analyzer
SECTION 3 MENUS
V1
V2
V3
V
V
V
A
A
A
I1
I2
I3
17:22
0.0
220.0
220.0
5.0
5.0
5.0
V
1 2 3
I
1 2
1 2 E
Measure
Meters
Alarms
Analysis
Instantaneous
Demand
Phasor diagram
Signals
Harmonics
Fig. 3-67 Measure Menu
3.2.2.1 Instantaneous Menu
This menu includes instantaneous values. If OK is pressed on this tab, the following
page appears on the screen. Operator can scroll inside Instantaneous values by
pressing right and left keys.
220.0
Measure->Instantaneous->V L-N
V1 V
V2
220.0
V
V3
220.0
V
Vo
220.0
V
Powers
V L-N V L-L
Fig. 3-68 Instantaneous Menu
• Line-to-neutral V (L-N) voltage for each phase and their average
• Line-to-line V(L-L) voltage for each phase and their average
• Phase currents (I) and their sum
• Neutral current (IN)
• CosØ for each phase and CosØ of system
• Power factor (PF) for each phase and power factor (PF) of system
• Active power (P) for each phase and their sum
• Reactive power (Q) for each phase and their sum
• Apparent power (S) for each phase and their sum
• Frequency (F) for each phase
• THDV values for each phase and their sum
• THDI values for each phase and their sum
• Total powers
