3.2.1.1.3.4 Start of day
Start of day can be adjusted between 0 - 23. (for Virtual Keyboard Refer to 3.1.4 E.g.).
3.2.1.1.3.5 Start of month
Start of month can be adjusted between 1 - 28. (for Virtual Keyboard Refer to 3.1.4 E.g.)
The settings listed below (between 3.2.1.1.3.6 and 3.2.1.1.3.17 ) are used to synchronize
the system electric meter and KLEA meter. Each of the below items can be adjusted
between 0.000
20000000000,0 (for Virtual Keyboard Refer to 3.1.4 E.g.).
Klea meters calculate energy by multiplying with CTR and VTR values.User should
take this fact into account when entering the below intial energy values.
3.2.1.1.3.6 T1 kWh
“Initial” value for meter of “Imp. Active =>T1” can be entered in this tab.
3.2.1.1.3.7 T1 kWh E
“Initial” value for meter of “Exp. Active=> T1” can be entered in this tab.
3.2.1.1.3.8 T1 kWh Imp. I.
“Initial” value for meter of “Reactive R1=>T1” can be entered in this tab.
3.2.1.1.3.9 T1 kWh Imp. C.
“Initial” value for meter of “Reactive R2=>T1” can be entered in this tab.
3.2.1.1.3.10 T1 kVArh Exp. I.
“Initial” value for meter of “Reactive R3=> T1” can be entered in this tab/
3.2.1.1.3.11 T1 kVArh Exp. C.
“Initial” value for meter of “Reactive R4=>T1” can be entered in this tab.
