26
4
Quadrant
Energy Analyzer
4
Quadrant
Energy Analyzer
Startup Settings
Language English
Date 07 January 2013
Time 17:45:28
CTR 1
VTR 1.0
Connection 3phase 4wire
Start
1
Low limit
1.0
High limit
5000.0
1 2 3 4
5 6 7 8
9 0 . -
ok clr
Fig. 3-7 Voltage Transformer Ratio
In order for KLEA to perform accurate measurements, current
transformer ratio should be entered correctly.
3.1.6 Connection
This menu contains information about how to connect KLEA to the panel/electrical
network.
There are 3 connection types:
• 3 phase – 4 wire connection
• 3 phase – 3 wire connection
• Aron connection
Initializing ..........................
Startup Settings
Language English
Date 07 January 2013
Time 17:45:28
CTR 1
VTR 1.0
Connection 3phase 4wire
Start
3phase 4wire
3phase 3wire
Aron
Fig. 3-8 Connection Types
SECTION 3 MENUS
