3.2.1.1.4.1 Input1 Menu
Input1 operates when DI1 and GND pins of KLEA are short circuited. Input1 menu has two settings:
• Mode
• Delay
3.2.1.1.4.1.1 Mode
Mode options are as seen below (Fig. 3-30). Press up and down keys to scroll inside
options. Press OK key to select the desired option.
Settings->Setup->Digital input->Input1
Mode Off
Delay 100
Off
2nd tariff
Counter
Fig. 3-30 Mode Selection
• Assume that for digital input 1, ‘2nd tari’ is selected as the mode setting. Under this
condition, when digital input 1 is short circuited (activated), tariff 1 meter will stop and
tariff 2 me er will start to count.
• Assume that for digital input 1, ‘Counter’ is selected as the mode setting. Under this
condition, each time DI1 and GND pins are short-circuited, “Meters->Digital input->
Digital input1 counter” counts (Fig. 3-30).
V1
V2
V3
V
V
V
A
A
A
I1
I2
I3
14:25
0.0
0.0
0.0
0.0
0.0
0.0
V
1 2 3
I
1 2
1 2 E
Meters
Alarms
Analysis
Imp. active
Exp. active
Reactive R1
Reactive R2
Other
Reactive R3
Reactive R4
Digital input
Meters->Digital input
Counter 1 0
Counter 2 0
Fig. 3-31 Digital Input1 Counter
