SECTION 3 MENUS
3.2.1.1.8.8 PF Menu
Alarm for power factor is adjusted in this submenu. Power factor settings are the same as
V(L-N). Low and high limit values can be adjusted between: 0
1
.
3.2.1.1.8.9 IN Menu
Alarm for neutral current is adjusted in this submenu. Neutral current settings are the
same as V(L-N). Low and high limit values can be adjusted between: 0
90000
3.2.1.1.8.10 F Menu
Alarm for frequency is adjusted in this submenu. Frequency settings are the same as V(L-N).
Low and high limit values can be adjusted between: 35
70
.
3.2.1.1.8.11 Temp. Menu
Alarm for temperature is adjusted in this submenu. Temperature settings are the same as
V(L-N). Low and high limit values can be adjusted between: -20
80.
When the low and high limit values are entered the same, KLEA will not issue an alarm.
Settings->Setup->Alarm->Current
Alarm relay Relay1
Low limit 0.0 A
Hysteresis 0.0 %
High limit 0.0 A
Delay 0.0 sec
Fig. 3-53 Setting for No Alarm
When operator enters a low limit value larger than the high limit, “Invalid limits. Please
check.” message appears on the screen.
