SECTION 2 INSTALLATION
2.3.2 Three Phase Connection No Neutral (3P3W)
L1
L2
L3
Current Measurement
Inputs
Voltage Measurement
Inputs
2A 2A 2A
L1 L2 L3 k1 k2 l1 l2 k3 l3
Fig. 2-7 KLEA 3 Phase Delta Connection Diagram
2.3.3 Three Phase No Neutral Aron Connection
Current Measurement
Inputs
Voltage Measurement
Inputs
L1
L2
L3
2A 2A 2A
L1 L2 L3 k1 k2 l1 l2 k3 l3
Fig. 2-8 KLEA Aron Connection Diagram
