3.2.1.1.1.1 Current Transformer Ratio
In this submenu current transformer ratio is entered. Inside Network menu, press up
and down keys to select CTR. Press OK key and KLEA virtual keyboard will appear on the
screen. The current transformer ratio (CTR) can be adjusted between 1 - 5000. (For Virtual
Keyboard Refer to 3.1.4 E.g.)
Settings->Setup->Network
CTR 1
VTR 1.0
Connection 3phase 4wire
Demand period 15 min
Power unit Kilo
10
Low limit
1
High limit
5000
1 2 3 4
5 6 7 8
9 0 . -
ok clr
Fig. 3-14 Setting Current Transformer Ratio
In order for KLEA to perform accurate measurements, current transformer ratio
should be entered correctly.
3.2.1.1.1.2 Voltage Transformer Ratio
In this submenu voltage transformer ratio is entered. Inside Network menu, press up and
down keys to select VTR. Press OK key and KLEA virtual keyboard will appear on the screen.
The voltage transformer ratio (VTR) can be adjusted between 1 - 5000.
(For Virtual Keyboard Refer to 3.1.4 E.g.). If a decimal number is to be entered as a VTR, with
the help of Klea arrow keys point to the
.
box on the Virtual Keyboard and press OK key.
In order for KLEA to perform accurate measurements, the voltage transformer ratio
should be entered correctly.
Settings->Setup->Network
CTR 1
VTR 1.0
Connection 3phase 4wire
Demand period 15 min
Power unit Kilo
1.0
Low limit
1.0
High limit
5000.0
1 2 3 4
5 6 7 8
9 0 . -
ok clr
Fig. 3-15 Setting Voltage Transformer Ratio
