Klemsan Klea 320P-D - T1_3 Start Time

37
4
Quadrant
Energy Analyzer
4
Quadrant
Energy Analyzer
NOTE: Assigned values also applies to the 4 quadrant counters.
("Exp. active "," Reactive R1 "," Reactive R2, " , " Reactive R3"," Reactive R4 ")
3.2.1.1.3.3 T1_3 StartTime
‘T1_3’ abbreviation refers to the third time slice of tariff 1 me er.
T1_3 start time can be adjusted between 0-23 (for Virtual Keyboard Refer to 3.1.4 E.g.).
“T1 rate3” meter (the second time slice of T1 meter - T1_3) counts between T1_3 start
time and T1_1 start time.
E.g.:
Assume that ‘T1_3 start time’ and ‘T1_1 start time’ are adjusted as 0 and 8 respectively.
“T1 rate 3 meter (T1_3)” counts starting from 16:00 and ceases at 00:00.
Settings->Setup->Energy
T1_1 start time 8 hr
T1_2 start time 16 hr
T1_3 start time 0 hr
Start of day 0 hr
Start of month 1
T1 kWh 1000.0 kWh
T1 kWh E. 1000.0 kWh
T1 kVArh Imp. I. 1000.0 kVArh
T1 kVArh Imp. C. 1000.0 kVArh
T1 kVArh Exp. I. 1000.0 kVArh
T1 kVArh Exp. C. 1000.0 kVArh
T2 kWh 1000.0 kWh
Meters->Imp. active
T1 rate 2 1000.0 kWh
T1 1000.0 kWh
T2 1000.0 kWh
T1 rate 1 1000.0 kWh
T1 rate 3 1000.0 kWh
Fig. 3-27 T1_3 start time
NOTE: Assigned values also applies to the 4 quadrant counters.
("Exp. active "," Reactive R1 "," Reactive R2, " , " Reactive R3"," Reactive R4 ")
SECTION 3 MENUS
If T1_1 and T1_2 have the same value, T1_1 and T1_3 counters count; If T1_1 and
T1_3 have the same value T1_1 and T1_2 counters count; if T1_2 and T1_3 have the
same value; T1_1 and T1_2 counters count, If T1_1, T1_2 and T1_3 have the same
value, only T1_1 counter will count.
