75
4
Quadrant
Energy Analyzer
4
Quadrant
Energy Analyzer
SECTION 3 MENUS
Meters->Imp. active
T1 kWh302500.0
T1 rate1 kWh99250.0
T1 rate2 98350.0 kWh
T1 rate3 kWh104900.0
T2 3506.0 kWh
Fig. 3-84 T1 rate3 import active energy
3.2.3.1.5 T2 Tab.
Import active energy values that belongs T2 are displayed as seen in the following
figure:
Meters->Imp. active
T1 kWh302500.0
T1 rate1
kWh
99250.0
T1 rate2 98350.0 kWh
T1 rate3 kWh104900.0
T2 3506.0 kWh
Fig. 3-85 Tariff 2 impo t active energy
While Tariff 2 me er is active; Tariff 1, T1 rate1, T1 rate2, T1 rate3 meters are not
active. (mutually exclusive).
In order for Tariff 2 o be active;
1-) “T2” mode should be selected in “digital input1” and/or “digital input2” menu,
2-) DI and GND pins of the selected input should be short-circuited.
(Refer to3.2.1.1.4 Digital input)
If ‘Tariff 2 mode is “NOT” SELECTED in the digital input menu, even though the
related digital input pins are short-circuited, Tariff 2 will not be a tive - Tariff
meter continues to operate.
