SECTION 3 MENUS
V2
V3
V
V
V
A
A
A
I 1
I 2
17:22
I 3
0.0
220.0
220.0
5.0
5.0
5.0
V
I
1 23
12
12 E
Alarms Analysis
Phase 3
Other
Phase 1
Phase 2
Fig. 3-87 Alarms Menu
3.2.4.1 Phase1 Menu
In Phase1 menu, phase1 alarm statuses are displayed.
“Normal”
No alarm
“Alarm”
Alarm
Alarms->Phase1
V Alarm
I Normal
P Normal
Q Normal
S Normal
CosØ Normal
NormalPF
V harmonics
Normal
THDV Normal
Normal
I harmonics
THDI Normal
F Normal
Fig. 3-88 Phase1 Menu
In Phase1 menu, following alarm statuses are monitored.
• V (phase-neutral voltage)
• I (current)
• P (active power)
• Q (reactive power)
• S (apparent power)
• cos Ø
• PF (power factor)
• V harmonics (any of 3., 5., - 21. harmonic alarm statuses ORed)
• THDV (total harmonic distortion in voltage)
• I harmonics (any of 3., 5., - 21. harmonic alarm statuses ORed)
• THDI (total harmonic distortion in current)
