SECTION 3 MENUS
V3
V
V
V
A
A
A
I 1
I 2
I 3
1 4 : 31
0.0
0.0
0.0
0.0
0.0
V
0.0
I
1 2 3
1 2
1 2 E
Meters Alarms Analysis
Exp. active
Reactive R1
Imp.active
Reactive R2
Reactive R3
Reactive R4
Digital input
Other
Fig. 3-80 Imp. Active Menu
3.2.3.1.1 T1 Tab.
Import active energy values that belongs T1 are displayed as seen in the following
figure:
Meters->Imp. active
T1 kWh
302500.0
T1 rate1 kWh
99250.0
T1 rate2
98350.0
kWh
T1 rate3 kWh
104900.0
T2
3506.0
kWh
Fig. 3-81 Imp. Active Energy Page
3.2.3.1.2 T1 Rate1 Tab.
T1 Rate1 meter that belongs to T1, counts between T1_1 start time and T1_2 start time.
Refer to: 3.2.1.1.3.1 and 3.2.1.1.3.2 for “T1_1 start time” and ” T1_2 start time”settings.
