SECTION 3 MENUS
3.2.3.2 Digital Input Menu
In this menu, counters belonging to digital inputs are displayed. Refer to 3.2.1.1.4 Digital
input to adjust a digital input as a counter.
When DI1 and GND pins are short-circuited for at least delay ( (Refer to 3.2.1.1.4.1.2 Delay)
time, “digital input1 counter” value increments by “1”.
When DI2 and GND pins are short-circuited for at least delay (Refer to 3.2.1.1.4.1.2 Delay)
time, “digital input2 counter” value increments by “1”.
Meters->Digital input
4
Counter 1
2
Counter 2
0
Counter 3
0
Counter 4
0
Counter 5
0
Counter 6
0
Counter 7
Fig. 3-86 Digital Input Menu(Dijital IO opsiyonlu model)
KLEA base model has2; optional digital IO model has 7 counters.
3.2.3.3 Others Menu
In this menu, consist of on hour counter, run hour counter and power interruption
counter. Only run hour counter can be deleted by users.
3.2.4 Alarms Menu
In this menu, alarms can be monitored. Alarms menu consists of ‘Phase1’,
‘Phase2’, ‘Phase3’ and ‘Other’ submenus.
In Klea ModeBUS table, 50 alarm statuses can be saved (Refer to Table 4.3).
If the number of alarm statuses exceeds 50; 51st alarm is overwritten on the first
alarm.
An alarm status consists of the below information:
