SECTION 3 MENUS
3.2.1.1.6 Analog Output Menu (Optional)
V1
V2
V3
V
V
V
A
A
A
I1
I2
I3
17:22
0.0
0.0
220.0
5.0
5.0
5.0
V
1 2 3
I
1 2
1 2 E
Setup
Date / Time
System info
Password
Restart
Default settings
Settings
Measure
Meters
Alarms Analysis
Network
Device
Energy
Digital input
Communication
Alarm
Clear
Digital output
Analog output
Output11
Output2
Output3
Output4
Fig. 3-37 Analog Output Menu
KLEA has two different optional analog output models; 2 analog output and 4 analog output models.
Operator can adjust KLEA to give output from analog output channels for the following
parameters: voltage, current, active power, reactive power, apparent power, frequency, phase-
phase voltages, neutral current, total current, total active power, total reactive power and total
apparent power pertaining to L1, L2, L3 phases.
Analog output channels can be adjusted to generate signals as 0-5V, 0-10V, -5-5V, -10- 10V,
0-20mA, 4-20mA. Analog output menu comprises of the following submenus.
Output1 (available in 2 analog and 4 analog outputs models)
Output (available in 2 analog and 4 analog outputs models)
Output3 (available only in 4 analog outputs model)
Output4 (available only in 4 analog outputs model)
3.2.1.1.6.1 Output1 Menu
Output1 menu comprises of the following submenus
• Input mode
• Output conn.
• Min. Value
• Max. Value
• Multiplier
