SECTION 3 MENUS
3.2.4.2 Phase2 Menu
“Phase2” menu consists of the same items as “Phase1” menu. Please refer to
3.2.4.1 Phase1 menu for details.
3.2.4.3 Phase3 Menu
“Phase3” menu consists of the same items as “Phase1” menu. Please refer to
3.2.4.1 Phase1 menu for details.
3.2.4.4 Other Menu
In “Other” menu, explanations are the same as in Phase1 menu.
Alarms->Other
VLL12 Normal
VLL23 Normal
VLL31 Normal
IN Alarm
Normal
Temperature
Battary
Normal
Fig. 3-89 Other Menu
In “Other” menu, following alarm statuses are monitored:
• VLL12 (phase1-phase2 voltage)
• VLL23 (phase2-phase3 voltage)
• VLL31 (phase3-phase1 voltage)
• IN (neutral current)
• Temperature
• Battery
When the battery voltage falls below 1.9 V value, Klea issues Battery alarm.
When Klea issues battery alarm, contact your local authorized dealer (or the
nearest authorized dealer).
3.2.5 Analysis Menu
It consists of submenus shown in Fig. 3-90. Analysis menu parameters can
also be reached from ModeBUS (Refer to 4.5.3 Archive Records).
