SECTION 3 MENUS
3.2.1.1.8.1 V(L-N) Menu
Inside‘Alarm’ menu, when V(L-N) is highlighted, press OK key and the following page will
appear on the screen.
Settings->Setup->Alarm->V(L-N)
Alarm relay Off
Low limit 0.0 V
High limit 0.0 V
Delay 0 sec
Hysteresis 0.0 %
Fig. 3-48 V(L-N) Menu
Alarm relay :
This setting is merely used to energize or not to energize a relay, when an alarm occurs.
For alarm relay setting, following options are available:
O : In case of V(L-N) alarm, none of the alarm relaysis energized
Relay1 : In case of V(L-N) alarm, relay 1 is energized
Relay2 : In case of V(L-N) alarm, relay 2 is energized
Press up and down keys to select the desired option and press OK key to complete the
setting.
Alarm relay Off
Fig. 3-49 Alarm Relay Setup
In order to adjust Klea to issue V (L-N) alarms, operator should adjust low limit and high
limit values as described below.
When V(L-N) of “any” of the three phases exceeds “Low limit” or “High Limit”, Klea gives
an alarm.
