Klemsan Klea 320P-D - Digital Output Connection Diagram; Device Dimensions

20
4
Quadrant
Energy Analyzer
4
Quadrant
Energy Analyzer
SECTION 2 INSTALLATION
NOTE: Any two-phase current can be connected to the current measuring inputs. L1 and L3 are
used in the figure above.
2.3.4 Digital Output Connection Diagram
DO (+)
DO (-)
+
-
External DC Power Supply must be connected.
(5-30VDC)
load
Fig. 2-9 Digital Output Connection Diagram
2.4 Dimensions
Dimensions are in millimeters.
Fig. 2-10 Dimensions
