3.2.1.1.2.5 Display on Time
Displayon time can be adjusted between 10
600 second.
(For Virtual Keyboard Refer to 3.1.4 E.g.).
3.2.1.1.3 Energy Menu
Initial energy values for T1, T1_1, T1_2, T1_3 and T2 can be entered inside this menu. Thus,
Toperator can synchronize the official electric meter with KLEA tariff meters. Operator
can navigate inside Energy menu by pressing up and down keys.
Settings->Setup->Energy
T1_1 start time 8 hr
T1_2 start time 16 hr
T1_3 start time 0 hr
Start of day 0 hr
Start of month 1
T1 kWh 1000.0 kWh
T1 kWh E 1000.0 kWh
T1 kVArh Imp. I. 1000.0 kVArh
T1 kVArh Imp. C. 1000.0 kVArh
T1 kVArh Exp. I. 1000.0 kVArh
T1 kVArh Imp. C. 1000.0 kVArh
T2 kWh 1000.0 kWh
Fig. 3-24 Energy Menu
3.2.1.1.3.1 T1_1 start time
Electric meters can have more than one tariff and also individual taris can be sliced in
time.
‘T1_1’ abbreviation refers to the first time slice of tariff 1 meter. T1_1 start time can be
adjusted between 0-23 (for Virtual Keyboard Refer to 3.1.4 E.g.).
“T1 rate1” meter (the first time slice of T1 meter - T1_1) counts between T1_1 start time
and T1_2 start time.
E.g.:
Assume that ‘T1_1 start time’ and ‘T1_2 start time’ are adjusted as 8 and 16 respectively.
“T1 rate1 meter (T1_1)” counts starting from 08:00 and ceases at 16:00.
SECTION 3 MENUS
