SECTION 3 MENUS
Settings->Setup->Analog output->Output1
Input mode V1 (L-N)
Output conn. 0-5V
Min. value 0.0
Max. value 0.0
Multiplier 1
Fig. 3-38 Output1
3.2.1.1.6.1.1 Input mode
Analog output will generate a signal in accordance with the parameter selected in Input
mode tab. Analog output examples will clarify the application of settings.
Input mode options are as follows:
V1(L-N)
V2(L-N)
V3(L-N)
I1
I2
I3
P1
P2
P3
Q1
Q2
Q3
S1
S2
S3
F
IN
VLL12
VLL23
VLL31
I tot.
P tot.
Q tot.
S tot.
