SECTION 3 MENUS
Meters->Imp. active
T1 kWh302500.0
T1 rate1 kWh99250.0
T1 rate2 98350.0 kWh
T1 rate3 kWh104900.0
T2 3506.0 kWh
Fig. 3-82 T1 rate1 import active energy
3.2.3.1.3 T1 Rate2 Tab.
T1 Rate2 meter that belongs to T1, counts between T1_2 start time and T1_3 start time.
Refer to: 3.2.1.1.3.2 and 3.2.1.1.3.3 for “T1_2 start time” and ” T1_3 start time”settings.
Meters->Imp. active
T1 kWh302500.0
T1 rate1 kWh99250.0
T1 rate2 98350.0 kWh
T1 rate3 kWh104900.0
T2 3506.0 kWh
Fig. 3-83 T1 rate2 import active energy
3.2.3.1.4 T1 Rate3 Tab.
T1 Rate3 meter that belongs to T1, counts between T1_3 start time and T1_1 start time.
Refer to: 3.2.1.1.3.3 and 3.2.1.1.3.1 for “T1_3 start time” and ” T1_1 start time”settings.
