SECTION 3 MENUS
Invalid limits!
Please check.
Settings->Setup->Alarm->Current
Alarm relay Relay1
Low limit 0.0 A
Hysteresis 0.0 %
High limit 0.0 A
Delay 0.0 sec
OK
X
Fig. 3-54 Invalid Limits message
3.2.1.1.8.12 Harmonics V Menu
Inside ‘Alarm’ menu, when Harmonics V is highlighted, press OK key and the following
page will appear on the screen.
Settings->Setup->Alarm->Harmonics V
Alarm relay Off
THDV hi limit 0.0 %
V3 hi limit 0.0 %
V5 hi limit 0.0 %
V7 hi limit 0.0 %
V9 hi limit 0.0 %
V11 hi limit 0.0 %
V13 hi limit 0.0 %
V15 hi limit 0.0 %
V17 hi limit 0.0 %
V19 hi limit 0.0 %
V21 hi limit 0.0 %
Delay 60 sec
Fig. 3-55 Harmonics Menu
Alarm relay:
Refer to 3.2.1.1.8.1 V(L-N) - Menu - Alarm relay setting.
THDV High Limit:
High limit value for total harmonic distortion - voltage alarm (For Virtual Keyboard
Refer to 3.1.4 E.g.). In order to set an alarm for THDV, operator should enter a high limit
value larger than zero. When high limit is entered as zero, THDV alarm will be deactivated
(no alarm will be set). It can be adjusted between 0
100.
