SECTION 3 MENUS
3.2.5.1.1.1 Phase1 Menu
Voltage(V), current(I), active power(P), reactive power(Q), apparent power(S), cos Ø,
power factor(PF), and frequency(F) values are displayed.
3.2.5.1.1.2 Phase2 Menu
Voltage(V), current(I), active power(P), reactive power(Q), apparent power(S), cos Ø,
power factor(PF), and frequency(F) values are displayed.
3.2.5.1.1.3 Phase3 Menu
Voltage(V), current(I), active power(P), reactive power(Q), apparent power(S), cos Ø,
power factor(PF), and frequency(F) values are displayed.
3.2.5.1.1.4 Other
VLL12(phase1-phase2 voltage), VLL23(phase2- phase3 voltage), VLL31(phase3-
phase1 voltage).
3.2.5.1.2 Daily Menu
This menu displays the minimum instantaneous values measured/calculated from start of
day (Refer to 3.2.1.1.3.4) up to present time. Its submenus are the same as “Hourly menu”.
3.2.5.1.3 Monthly Menu
This menu displays the minimum instantaneous values measured/calculated from
start of month (Refer to 3.2.1.1.3.5) and start of day Refer to 3.2.1.1.3.4), up to present
time. Its submenus are the same as “Hourly menu”.
3.2.5.2 Maximum Menu
Submenus and explanations of“Maximum” menu are the same as“Minimum” menu. The
values measured in the “Maximum” menu are also “instantaneous” maximum values.
3.2.5.3 Average Menu
Submenus and explanations of “Maximum” menu are the same as “Minimum” menu.
In “Average” menu, hourly, daily and monthly average values are displayed.
