Korg PA1000 User Manual

Shaping the sound of the lead voice |511
Adding EQ, compression and gate to the lead voice
While in the Global > Mic Setup > EQ/Dynamic page, you can program equal-
ization, compression and gate for the lead voice.
Programming the EQ
This is an extremely flexible 3-band EQ with frequency and gain-adjustable
high and low shelving bands, as well as a fully parametric band with Q con-
trol.
▪ Use the On/Off button to turn the EQ on or off.
▪ Use the Gain (upper) and Frequency (lower) controls to create the EQ curve.
The Low and High Gain controls boost or cut all frequencies below or above
the frequencies set by the Frequency controls. These are most like the com-
mon Bass and Treble controls on a stereo system.
The Mid Gain control boosts or cuts the frequencies within a selected band
that is defined by a center frequency (Frequency control) and a width con-
trol (Q parameter). For vocals, the gain of a narrow parametric band is typi-
cally reduced to overcome room or voice resonances and smooth the sound
although experienced users may boost a band felt to be missing in a particu-
lar voice as well.
EQ Band Frequency Gain Q
Low 20 Hz … 1.00 kHz ±18 dB –
Mid 50 Hz … 10.00 kHz ± 18 dB 0.5 … 10.0
High 500 Hz … 20.00 kHz ±18 dB –

Korg PA1000 Specifications

General

Sound Engine	EDS-X (Enhanced Definition Synthesis-eXpanded)
Polyphony	128 voices
Keyboard	61 keys with velocity and aftertouch
Display	7-inch TFT display
Song Player	MP3, SMF (Standard MIDI File), KAR
Storage	960 MB
Connectivity	USB, MIDI, Audio In/Out
Weight	10.75 kg (23.7 lbs)
Effects	148 effect types
Sounds	Over 1, 750 Factory Sounds, 107 Drum Kits
User PCM Sample Memory	600 MB
Style Tracks	8 tracks
Chord Sequencer	Yes
Pads	4 Assignable Pads
Lyrics	MID, KAR, MP3+Lyrics
Sequencer	16 tracks
SongBook	Fully programmable music database
Multi Pad	4 Assignable Pads
Connections	Audio In, Line Out
Clock	Internal
Power Supply	AC adapter
