Kyocera KM-4035

1-3-6
2FD/2FF/2FG-3.0
6. Pull upper and lower drawers out and remove the
tape holding each of the drawer lift.
*If necessary, please fix the cassette cursor with
the screws included in the machine box.
1. Install the optional paper feeder or large paper
deck as necessary (see page 1-3-13 to 1-3-21).
1. Remove the two pins for light source unit 1 and
the pin for light source unit 2.
Figure 1-3-5
Figure 1-3-6
Remove the pins holding light source units 1 and 2.
Tape
Light source unit 2 pin
Light source unit 1 pins
Install the optional paper feeder or large paper deck.
Install the original cover or the DP.
Install other optional devices.
1. Install the original cover or DP (see page 1-3-33 when installing the DP).
1. Install the optional devices (job separator, finisher, fax board, and/or printer board etc.) as necessary.
