Kyocera KM-4035

2FD/2FF/2FG
1-4-51
Maintenance
Description
item No.
U247 Checking the operation of large paper deck and paper feeder
Description
Tu r ns on motors and clutches of optional large paper deck or paper feeder.
Purpose
To check the operation of motors and clutches of paper feed device.
Start
1. Press the start key. The screen for selecting an item is displayed.
2. Select the device to be checked.
Display Paper feed device
3000 DECK Large paper deck
500 × 2 DECK Paper feeder
Method
1. Select the item to be operated. The selected item is displayed in reverse and operation starts.
Large paper deck
Display Motors and clutches Operation
LCF MOT Conveying motor (CM) On for 5 s
B CL Conveying clutch (CCL) On for 1 s
PCL1 Paper feed clutch 1(PFCL1) On for 1 s
PCL2 Paper feed clutch 2(PFCL2) On for 1 s
Paper feeder
Display Motors and clutches Operation
DESK MOT Desk Drive motor (DDM) On for 5 s
FEED CL Desk feed clutch (DFCL) On for 1 s
UPP CL Desk upper paper feed clutch (DPFCL-U) On for 1 s
LOW CL Desk lower paper feed clutch (DPFCL-L) On for 1 s
2. To return to the screen for selecting an item, press the stop/clear key.
Completion
Press the stop/clear key at the screen for selecting an item. The screen for selecting a maintenance item No. is
displayed.
