Kyocera KM-4035

2FD/2FF/2FG
2-3-3
Connector Pin No. Signal I/O Voltage Description
TB
Connected
to the AC
power plug
and power
relay.
CN3
Connected
to the 3000-
sheet
finisher* or
booklet
stitcher*.
YC1
Connected
to the safty
switch 1,
safty switch
2 and main
PCB.
YC2
Connected
to the main
PCB.
YC3
Connected
to the paper
feeder*/
large paper
deck* and
mailbox*/
switchback
unit*.
YC4
Connected
to the
cooling fan
motor 4.
TB1 LIVE I 120 V AC 120 V AC supply
TB1 LIVE I 220-240 V AC 220-240 V AC supply
TB2 COM I 120 V AC 120 V AC supply
TB2 COM I 220-240 V AC 220-240 V AC supply
TB3 NEUTRAL O 120 V AC 120 V AC supply
TB3 NEUTRAL O 220-240 V AC 220-240 V AC supply
TB4 LIVE I 120 V AC 120 V AC supply
TB4 LIVE I 220-240 V AC 220-240 V AC supply
TB5 LIVE O 120 V AC 120 V AC supply
TB5 LIVE O 220-240 V AC 220-240 V AC supply
1 24V O 24 V DC 24 V DC supply
2 24V O 24 V DC 24 V DC supply
3 24V O 24 V DC 24 V DC supply
4 24V O 24 V DC 24 V DC supply
5 GND - - Ground
6 GND - - Ground
7 GND - - Ground
8 GND - - Ground
9 GND - - Ground
10 5.1V O 5.1 V DC 5.1 V DC supply
1 24V O 24 V DC 24 V DC supply for SSW1
2 GND - - Ground
3 GND - - Ground
4 GND - - Ground
5 3.4V O 3.4 V DC 3.4 V DC supply for MPCB
6 3.4V O 3.4 V DC 3.4 V DC supply for MPCB
7 3.4V O 3.4 V DC 3.4 V DC supply for MPCB
8 5.1V O 5.1 V DC 5.1 V DC supply for MPCB
9 5.1V O 5.1 V DC 5.1 V DC supply for MPCB
10 24V I 24 V DC 24 V DC supply for MPCB
1 HEATERON O 0 to 5 V DC Heater current monitor signal
2 GND - - Ground
3 FH-S I 0/5 V DC FH-S ON/OFF
4 FH-M I 0/5 V DC FH-M ON/OFF
5 5.1V I 5.1 V DC 5.1 V DC supply from MPCB
6 ZCROSS O 0/5 V DC (pulse) Zero-cross signal
11 5.1V I 5.1 V DC 5.1 V DC supply
12 GND - - Ground
13 GND - - Ground
14 24V I 24 V DC 24 V DC supply
15 24V I 24 V DC 24 V DC supply
16 24V I 24 V DC 24 V DC supply
17 5.1V I 5.1 V DC 5.1 V DC supply
18 GND - - Ground
19 GND - - Ground
20 GND - - Ground
1 CFM4 REM O DC0V/24V CFM4 ON/OFF
2 24V O 24 V DC 24 V DC supply for CFM4
*: Optional
