Connector Pin No. Signal I/O Voltage Description
CN5
Connected
to the LCD.
CN6
Connected
to the back
light.
1 LCD FRAME O 0/5 V DC (pulse) LCD FRAME signal
2 LCD LOAD O 0/5 V DC (pulse) LCD LOAD signal
3 LCD CP O 0/5 V DC (pulse) LCD CP signal
4 LCD VSS(SG) O GND LCD VSS signal
5 LCD VDD(+5V) O 5 V DC LCD VDD signal
6 LCD VSS(SG) O GND LCD VSS signal
7 LCD CONT O Analog LCD control signal
8 LCD DISP OFF O 0/5 V DC LCD DISPLAY signal
9 LCD D0 O 0/5 V DC (pulse) LCD D0 data
10 LCD D1 O 0/5 V DC (pulse) LCD D1 data
11 LCD D2 O 0/5 V DC (pulse) LCD D2 data
12 LCD D3 O 0/5 V DC (pulse) LCD D3 data
1 CCFT HOT O Analog LCD BACK LIGHT control signal
2 N.C - - Not used
3 N.C - - Not used
4 CCFT COLD O - LCD BACK LIGHT control signal
