Kyocera KM-4035

2FD/2FF/2FG
2-3-24
Connector Pin No. Signal I/O Voltage Description
1 GND - - Ground
2 SHPSW O 0/5 V DC SHPSW ON/OFF
3
LAMP ON REM I 0/5 V DC EL ON/OFF
4
SM ENABLE I 0/5 V DC SM ENABLE signal
5 SM RET I 0/5 V DC SM RET signal
6 SM CWB I 0/5 V DC SM CWB signal
7 SM CLK I 0/5 V DC (pulse) SM CLOCK signal
8 SM M5 I 0/5 V DC SM drive control voltage M5
9 SM M4 I 0/5 V DC SM drive control voltage M4
10 SM M3 I 0/5 V DC SM drive control voltage M3
11 SM M2 I 0/5 V DC SM drive control voltage M2
12 SM M1 I 0/5 V DC SM drive control voltage M1
13 SM VREF I 0/5 V DC SM current control voltage Vref
14 ODSW I 0/5 V DC ODSW ON/OFF
1 /B O 0/24 V DC (pulse) SM coil energization pulse (_B)
2 24V O 24 V DC 24 V DC supply for SM
3 B O 0/24 V DC (pulse) SM coil energization pulse (B)
4 A O 0/24 V DC (pulse) SM coil energization pulse (A)
5 24V O 24 V DC 24 V DC supply for SM
6 /A O 0/24 V DC (pulse) SM SM coil energization pulse (_A)
1 LAMP ON O 0/5 V DC EL ON/OFF
2 LAMP ON O 0/5 V DC EL ON/OFF
3 24V O 24 V DC 24 V DC supply for INPCB
4 24V O 24 V DC 24 V DC supply for INPCB
5 GND - - Ground
6 GND - - Ground
1 5V O 5 V DC 5 V DC supply for SHPSW
2 SHPSW I 0/5 V DC SHPSW ON/OFF
3 GND - - Ground
1 5V O 5 V DC 5 V DC supply for ODSW
2 ODSW I 0/5 V DC ODSW ON/OFF
3 GND - - Ground
1 GND - - Ground
2 24V I 24 V DC 24 V DC supply form PSPCB
3 GND - - Ground
4 5V I 5 V DC 5 V DC supply form PSPCB
YC1
Connected
to the main
PCB.
YC2
Connected
to the
scanner
motor.
YC3
Connected
to the
inverter
PCB.
YC4
Connected
to the
scanner
home
position
switch.
YC5
Connected
to the
original
detection
switch.
YC6
Connected
to the
power
source
PCB.
