Kyocera KM-4035

2FD/2FF/2FG
2-3-26
Connector Pin No. Signal I/O Voltage Description
CN1
Connected
to the main
PCB.
1 RS- I 0/5 V DC (pulse) RS - signal
2 RS+ I 0/5 V DC (pulse) RS + signal
3 CLK+ I 0/5 V DC (pulse) CLOCK + signal
4 CLK- I 0/5 V DC (pulse) CLOCK - signal
5 GND - - Ground
6 SHIFT I 0/5 V DC (pulse) SHIFT signal
7 GND - - Ground
8 CLP I 0/5 V DC (pulse) CLP signal
9 GND - - Ground
10 5.1V I 5.1 V DC 5.1 V DC supply from MPCB
11 12V I 12 V DC 12 V DC supply from MPCB
12 EVEN O 4.5 V DC (pulse) EVEN signal (analog)
13 GND - - Ground
14 ODD O 4.5 V DC (pulse) ODD signal (analog)
15 GND - - Ground
IC4
IC1
IC3
CN1
142
151
Figure 2-3-11 CCD PCB silk-screen diagram
